ARCA HEARTH

Key Features

• ISO 20ft Standard Dry Van container base — stackable, towable, crane-liftable
• Full 3/4" PEX plumbing system — hot + cold supply lines throughout
• On-demand propane tankless water heater — wall-mounted, instant hot water
• Propane direct-vent wall heater (30,000 BTU) — dedicated space heat, no electricity required
• Shower stall — tempered glass door, rainfall + handheld heads, tiled base
• Full-flush toilet with macerator pump — no gravity drain required
• Kitchenette — 2-burner propane stove, stainless undermount sink, solid cabinetry
• Under-counter refrigerator rough-in (110V dedicated circuit)
• Gray water drain system — shower + sink routed to exterior stub-out
• Black water macerator line — stub to external holding tank or direct site connection
• Dedicated LP supply line — exterior stub-out with shutoff for generator/BBQ tee
• PVC composite interior panels throughout — moisture-resistant, cleanable
• 2×3 stud framing — closed-cell spray foam insulation, vapor-sealed
• Radiant barrier MDF sheathing — reflective foil face inward
• Mini-split HVAC — 1-ton 12,000 BTU, heat + cool, 110V
• Electrical rough-in + 100A distribution panel — all circuits labeled
• 5kW solar-hybrid inverter included — battery and solar upgradeable
• Exterior LP quick-connect port — compatible with 20 lb / 100 lb propane tanks
• Dual exterior NEMA 14-50 outlets — shore power or generator input
